Compressor Processes Liquids | Works With Any Lift System | No Pneumatic Valves or Vessels | Automated Capacity Control | SkyView Reporting | Set & Forget PLC Control
Standard Features
- Purpose design for low volume casing gas applications
- No operator setup or adjustment is required
- Eliminates issues common with conventional casing gas compressors
- No liquid handling system (compressor can pump liquid or gas)
- NO separator, level shutoff or switch
- NO liquid pump
- No liquid handling system (compressor can pump liquid or gas)
- Ultra-reliable gear pump and electric motor power supply
- Minimal moving parts, minimal maintenance
- Easy and inexpensive to move
- Live SkyView reporting system instantly notifies of system warnings and shutdowns
- No external leak points for oil or gas seals
- Automatic restart if grid power is lost
- Optimize separately from the lift system
- Compressor will adjust cycle rate to match flow
- Up to 100% turn down
- Start and walk away oil warm-up system
Options/Configurations
- Multiple Rod Sizes Available
- Sweet or Sour Service
- Skid or Gas Trailer Available – towable by a ¾ ton truck
- Electric or Gas Drive Engine Power Packs
- Hydraulic Heat Trace
- Sour Corrosion PSV
- Sour Corrosion XXS Piping
- Inlet Particle Filter
| Motor | 15hp |
| Operating Pressure Range | 0 - 1500psi |
| Flow Range | 0 - 200mscfd |
| HCG15 Compressor Weight | 612 lbs |
| Power Pack Weight | 1285 lbs (Electric) |
| Power Pack Weight | 2270 lbs (Gas) |
| Compressor Dimensions (on Base) | Length: 97.5" Width: 24" Height: 71" |
| Compressor Dimensions (off Base) | Length: 97.5" Width: 20" Height: 63" |
| Power Pack Dimensions (Electric) | Length: 67.5" Width: 49.5" Height: 66.5" |
| Power Pack Dimensions (Gas) | Length: 86.5" Width: 55.5" Height: 92" |
| Test Trailer Dimensions (Gas) | Length: 181" Width: 86" Height: 96" |
| Casing Gas Compression (Sweet & Sour Service) |
| Pigging |
| Poor Boy Gas Lift |
| Multi-phase pump |
 |
HCG Brochure
HCG Application Data SheetPerformance
CHC0615 with HC613 Compressor
| DISCHARGE PRESSURE Max ΔP: 225 psi / 1550 kPa | |||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SUCTION |
PSI kPa |
75 520 |
100 700 |
125 860 |
150 1035 |
175 1205 |
200 1380 |
225 1550 |
250 1725 |
275 1900 |
300 2070 |
325 2240 |
350 2420 |
| 5 35 |
37 1.1 |
36 1.1 |
35 1.0 |
34 1.0 |
33 0.9 |
32 0.9 |
32 0.9 |
||||||
| 10 70 |
47 1.4 |
46 1.4 |
46 1.3 |
45 1.3 |
44 1.3 |
43 1.2 |
42 1.2 |
||||||
| 15 105 |
58 1.7 |
57 1.7 |
56 1.7 |
55 1.6 |
54 1.6 |
53 1.5 |
52 1.5 |
||||||
| 20 140 |
69 2.1 |
68 2.0 |
67 2.0 |
66 1.9 |
65 1.9 |
64 1.9 |
63 1.8 |
||||||
| 30 210 |
90 2.7 |
89 2.7 |
88 2.6 |
87 2.6 |
86 2.5 |
85 2.5 |
84 2.5 |
83 2.4 |
|||||
| 40 275 |
112 3.4 |
110 3.3 |
109 3.3 |
108 3.2 |
107 3.2 |
106 3.1 |
105 3.1 |
104 3.0 |
|||||
| 50 345 |
133 4.0 |
132 4.0 |
131 3.9 |
129 3.9 |
128 3.8 |
127 3.8 |
126 3.7 |
125 3.7 |
124 3.6 |
||||
| 75 520 |
186 5.3 |
184 5.3 |
183 5.2 |
181 5.2 |
180 5.2 |
179 5.1 |
177 5.1 |
176 5.0 |
175 4.9 |
||||
| 100 700 |
238 6.8 |
237 6.8 |
235 6.7 |
233 6.7 |
232 6.6 |
230 6.6 |
229 6.5 |
227 6.4 |
|||||
| 125 860 |
291 8.3 |
289 8.3 |
287 8.2 |
285 8.2 |
283 8.1 |
282 8.0 |
280 7.9 |
||||||
| 150 1035 |
344 9.8 |
341 9.8 |
339 9.7 |
337 9.6 |
335 9.6 |
333 9.5 |
331 9.4 |
||||||
| 175 1205 |
396 11.3 |
394 11.3 |
391 11.2 |
389 11.1 |
387 11.1 |
385 11.0 |
383 10.9 |
||||||
| 200 1380 |
449 12.8 |
446 12.7 |
443 12.6 |
441 12.6 |
439 12.5 |
436 12.4 |
|||||||
| Projected Performance based on 2500 ft, gas density .665, temp 68ºF – Flow Rates in mscfd e3m3/day | |||||||||||||
CHC0615 with HC616 Compressor
| DISCHARGE PRESSURE Max ΔP: 350 psi / 2410 kPa | ||||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
SUCTION |
PSI kPa |
200 1380 |
225 1550 |
250 1720 |
275 1900 |
300 2070 |
325 2240 |
350 2410 |
375 2590 |
400 2760 |
425 2930 |
450 3100 |
475 3280 |
500 3450 |
| 5 30 |
20 0.6 |
19 0.5 |
19 0.5 |
18 0.5 |
17 0.5 |
16 0.5 |
16 0.5 |
|||||||
| 10 70 |
27 0.8 |
26 0.7 |
26 0.7 |
25 0.7 |
24 0.7 |
23 0.7 |
23 0.7 |
|||||||
| 15 100 |
34 1.0 |
33 0.9 |
32 0.9 |
32 0.9 |
31 0.9 |
30 0.9 |
29 0.8 |
|||||||
| 20 140 |
41 1.2 |
40 1.1 |
39 1.1 |
39 1.1 |
38 1.1 |
37 1.1 |
36 1.0 |
|||||||
| 30 210 |
55 1.6 |
54 1.5 |
54 1.5 |
53 1.5 |
52 1.5 |
51 1.5 |
50 1.4 |
49 1.4 |
||||||
| 40 280 |
70 2.0 |
69 2.0 |
68 1.9 |
67 1.9 |
66 1.9 |
65 1.9 |
64 1.8 |
63 1.8 |
||||||
| 50 340 |
84 2.4 |
83 2.4 |
82 2.3 |
81 2.3 |
80 2.3 |
79 2.3 |
78 2.2 |
77 2.2 |
76 2.2 |
|||||
| 75 520 |
114 3.3 |
114 3.3 |
113 3.2 |
112 3.2 |
111 3.2 |
111 3.2 |
110 3.1 |
109 3.1 |
109 3.1 |
108 3.1 |
||||
| 100 690 |
148 4.2 |
147 4.2 |
146 4.2 |
146 4.2 |
145 4.1 |
144 4.1 |
143 4.1 |
143 4.1 |
142 4.1 |
141 4.0 |
141 4.0 |
|||
| 125 860 |
182 5.2 |
181 5.2 |
180 5.1 |
179 5.1 |
179 5.1 |
178 5.1 |
177 5.1 |
176 5.0 |
175 5.0 |
174 5.0 |
174 5.0 |
173 4.9 |
||
| 150 1030 |
217 6.2 |
215 6.1 |
214 6.1 |
213 6.1 |
212 6.1 |
211 6.0 |
210 6.0 |
210 6.0 |
209 6.0 |
208 5.9 |
207 5.9 |
206 5.9 |
205 5.9 |
|
| 175 1210 |
251 7.2 |
250 7.1 |
249 7.1 |
247 7.1 |
246 7.0 |
245 7.0 |
244 7.0 |
243 6.9 |
242 6.9 |
241 6.9 |
240 6.9 |
239 6.8 |
239 6.8 |
|
| 200 1380 |
284 8.1 |
283 8.1 |
282 8.1 |
281 8.0 |
279 8.0 |
278 7.9 |
277 7.9 |
276 7.9 |
275 7.9 |
274 7.8 |
273 7.8 |
272 7.8 |
||
| Projected Performance based on 2500 ft, gas density .665, temp 68ºF – Flow Rates in mscfd e3m3/day | ||||||||||||||
